Model No. : SE-GS-1016

  Desktop 16 port 10/100/1G  Ethernet Switch

 Features :


SE-GS-1016 Gigabit Ethernet Switch, mini desktop Switch, is designed to solve data transfer bottleneck in the enterprises and Internet Cafe. It has 16 10/100/1000Mbps auto-negotiation Ethernet ports and high-speed dynamic memory, supports auto MDI/MDI-X and store-and-forward function to ensure the data to be sent effectively. In addition, the Gigabit ports can be used as normal ports, as well as Uplink ports to connect backbone network. You can replace 10/100Mbps Switch with SE-GS-1016/1024 to enhance your network. because the speed at each port can be up to 2000Mbps for full-duplex mode. "Plug and play" function assists you to set up easily.

  • 16 10/100/1000Mbps ports connect to the workstation and support MDI/MDIX
  • Compatible with the IEEE802.3, IEEE802.3u, IEEE802.3ab Ethernet standards
  • Supports NWAY auto-negotiation function, auto-detect transfer data rate, UPnP, full-duplex, and automatically chooses the best network connectivity mode
  • Supports Auto MDI/MDIX function, predigests the network span and maintenance.
  • Supports IEEE802.3x full-duplex flow control, and half-duplex backpressure flow control
  • Supports non-blocking line speed transfer
  • Offers diagnosis and status LED indicators
  • Adopts store-and-forward mode, supports MAC Address auto-learning function and integrates 8K MAC Address Table
     Specifications :
Transmission Media : 10Base-T:Cat.3 or 3e UTP;; 100Base-TX:Cat.5 UTP;; 1000Base-T:Cat.5e UTP
Ports : 16 RJ-45 ports and 10/100/1000Mbps per port
Consumption : 25 W
AC adapter output range : 12V 2500 mA
Storage temperature  : -40℃~70℃
Storage Humidity : 5%~90% RH no condensing
Operating temperature : 0℃~40℃
Operating Humidity : 10%~90% RH no condensing
Filtering Address Table : 8K
Backplane Bandwidth : 32 Gbps
Standards and Protocols Supported : IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x

Approval : CE / FCC

     Package Content :
  • SE-GS-1016 switch
  • External Power Adapter
  • User manual
