Features
:
¡@
The QUAD BAY
NAS server allows workstations access data with same network connections,
and share the date through internet with FTP server. Back up important
data
time to time even under different locations, Embedded with Smart RAID
technology, provide RAID 0, RAID 5, JBOD to secure and protect valuable
data. It is
accessible by all kinds of OS users Windows, Mac, and Linux with a total
capacity of up to 4T.
-
Patented case mechanism design
-Magnetic door opening and
removable HDD design, no tools required.
-
Useful LCD display -Which
enable users to monitor the hard drive status, Raid status, IP
address, and check potential problems.
-
Easy Hard disk installation -Breakthrough
and innovation design, install /uninstall 4 HDD in a minute. Patent
protected world wide.
-
Disk Array RAID 0/1/5, JBOD Mode -To
ensure the data security, QUAD NAS offers advanced disk
configurations for RAID 0/1/5/, Single, and JBOD. RAID 5
allows one
hard drive failure. Therefore, when 1 drives fail in RAID 5, and
users can still rescue their critical data. This effectively lowers
down the risk of data
loss caused by failure of hard disks.
-
Printer Server -You
can share your printer device over the network by simply connecting
a USB printer to NAS USB port and enabling the printer sharing
function.
-
NAS to NAS incremental Back up -Files can
be backed up from QUAD BAY NAS to other QUAD BAY NAS in remote
locations. it is most reliable ad cost effective solution to prevent
entire company data has been stolen or damaged caused by fire or nay
other disaster.
-
File Server (SAMBA) -QUAD
BAY NAS allows server manager to create user ID and password, and
define the authority and quota for each user.
-
FTP server -By
using QUAD NAS , you can manage the access authority of the FTP
server and share your files with your friends or customers easily in
a few steps.
-
Backup server with auto-backup software -The
automatic backup software, SyncQuick Backup, is provided for users
to perform real-time synchronization or schedule backup from
multiple PCs to QUAD BAY NAS.
-
UPnP, DLNA Media Server -4
BAY QUAD
NAS
is a perfect media storage center and it works well with DLNA
(Digital Living Network Alliance) compliant media players. You can
play the photos and videos on TV.
-
Share
your music by iTunes Server -All
your MP3 music can be collectively stored and streamed to Mac or
Windows PC. Just turn on the iTunes program and
enjoy all the music
around your home network.
-
Bit Torrent download engine -The
QUAD BAY NAS serves as a continuous Bit torrent download machine
without turning on your PC.
-
Support
Windows, Mac, Linux
-QUAD
BAY NAS is specially designed for different users to share the files
across Windows, Mac, Linux environment.
|
| ¡@ |
¡@
|
Model:
|
SE-NAS-09G |
|
Product
name: |
QUAD HDD
GIGABITS NAS |
|
CPU:
|
300Mhz
|
|
RAM:
|
128MB DDR |
|
Interface/ ports:
|
LAN
(RJ-45) (10/100/1000BASE-TX) (Giga LAN)
USB1.1 (for Print server ) |
|
LCD
Display |
IP
Address/ Mac Address/ HDD Capacity / RAID Level/ RAID Status.
|
|
Data
transfer rate: |
Upload
12MB/s, Download 25MB/s (SAMBA)
|
|
Power
supply: |
Internal
Power supplier |
|
Supporting Protocol |
TCP/IP,
NBNS (Net BIOS Name Server), Microsoft Networks (CIFS/SMB), DHCP
Server/Client (Auto detection), SNTP Client |
|
IP
Acquisition Method |
Automatic/Manual |
|
System
Time |
Supporting NTP (Network Time Protocol Server) |
|
Supporting Hard Disk |
Up to 4
x SATA I/II Hard Disk ( 4 x 1T total 4T capacity ) |
|
System
file |
FAT32/
EXT2/EXT3 |
|
Product
Dimension |
140(W)x
222(D)x184(H) mm (main body) |
|
Weight
|
3000 g
(Exclude hard disk) |
|
Operation Environment : |
Operation Temperature: 0C ~ 70C , Operation Humidity: 10~90RH
|
|
Storage
Environment: |
Storage
Temperature: -20C ~ 70C , Storage Humidity: 5~95RH
|
|
Certification: |
CE, FCC
Certified |
All specifications
are subject to change without notice.
Approval :
CE / FCC
¡@ |
